Rotating joint type RL-MD – modular design with bellows system cartridge, solid grease ballbearings, for universal use Product characteristics:universal use – cooling, heating, clampingwith bellows sealingModular unit design – customer taylered configuration, fast and economiccartridge fast change CD-cartridge-designsealingmaterial ceramics/graphite. For coking heat transfer oil with temperature higher than 230 °C – Version HT with diamondhard sealface and hightemperature graphitesealringsolid grease ballbearings – maintenance freeno elastomers – therefore no temperature- and chemical resistance problemsno loose parts, f.e. springsrobust and less influence of dirty mediaself supporting – no additional support necessaryavailable in stainless steelSize:DN 50 (2")DN 65 (2 1/2")DN 80 (3")DN 100 (4")

Product characteristics:steel (zinc plated) or stainless steelNitril-seal (Viton optional)built-in ball guiding tracks similar to ball bearingsswiveling, rotating movements with low speedfor simple applications for example hose reels

Multiport rotating joints 1-2 passages for around the shaft mounting Product characteristics:around the shaft mounting when no free shaft end ist availablebrass housing1 and 2 passages 1/4"special sealings for water, air and oilmechanical seals
